2.3.2.4 LD0.IL1TCTR1 Three-phase CT supervision (1)
Table 80: LD0.IL1TCTR1 Three-phase CT supervision (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.IL1TCTR1
.Alm.stVal ALARM Alarm 1=Alarm
.mcd
.Wrn.stVal WARNING Warning 1=Warning
.mcd
2.3.2.5 LD0.IL1TCTR2 Three-phase CT supervision (2)
Table 81: LD0.IL1TCTR2 Three-phase CT supervision (2)
BitA RegA IEC 61850 name SA name Description Values
LD0.IL1TCTR2
.Alm.stVal ALARM Alarm 1=Alarm
.mcd
.Wrn.stVal WARNING Warning 1=Warning
.mcd
2.3.2.6 LD0.LDPRLRC1 Load profile record (1)
Table 82: LD0.LDPRLRC1 Load profile record (1)
BitA
RegA IEC 61850 name SA name Description Value
LD0.LDPRLRC1
.MemWrn.stVal Recording memory warning 1=Warning
.mcd
.MemAlm.stVal Recording memory alarm 1=Alarm
.mcd
2.3.2.7 LD0.MAPGAPC7 Multipurpose protection (7)
Table 83: LD0.MAPGAPC7 Multipurpose protection (7)
BitA
RegA IEC 61850 name SA name Description Values
LD0.MAPGAPC7
.Str.general START Stage start 1 = Start
.mcd
.Op.general OPERATE Stage operate 1 = Operate
.mcd
Section 2 1MRS756878 H
Modbus data mappings
48 RET615
Point List Manual
