ABB RET615 - LD0.RESCMMXU2 Residual Current Measurement (2); LD0.RESVMMXU1 Residual Voltage Measurement (1); LD0.ROVPTOV1 Residual Overvoltage Protection (1); LD0.ROVPTOV2 Residual Overvoltage Protection (2)

2.3.1.53 LD0.RESCMMXU2 Residual current measurement (2)
Table 56: LD0.RESCMMXU2 Residual current measurement (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.RESCMMXU2
2764 172.12 .HiAlm.stVal HIGH_ALARM High alarm 1=Alarm
2765 172.13 .mcd
2766 172.14 .HiWrn.stVal HIGH_WARN High warning 1=Warning
2767 172.15 .mcd
2.3.1.54 LD0.RESVMMXU1 Residual voltage measurement (1)
Table 57: LD0.RESVMMXU1 Residual voltage measurement (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.RESVMMXU1
3048 190.08 .HiAlm.stVal HIGH_ALARM High alarm 1=Alarm
3049 190.09 .mcd
3050 190.10 .HiWrn.stVal HIGH_WARN High warning 1=Warning
3051 190.11 .mcd
2.3.1.55 LD0.ROVPTOV1 Residual overvoltage protection (1)
Table 58: LD0.ROVPTOV1 Residual overvoltage protection (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.ROVPTOV1
3168 198.00 .Str.general START General start 1=Start
3169 198.01 .mcd
3170 198.02 .Op.general OPERATE General operate 1=Operate
3171 198.03 .mcd
2.3.1.56 LD0.ROVPTOV2 Residual overvoltage protection (2)
Table 59: LD0.ROVPTOV2 Residual overvoltage protection (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.ROVPTOV2
3172 198.04 .Str.general START General start 1=Start
3173 198.05 .mcd
3174 198.06 .Op.general OPERATE General operate 1=Operate
3175 198.07 .mcd
1MRS756878 H Section 2
Modbus data mappings
RET615 37
Point List Manual
