ABB RET615 - LD0.TRPPTRC3 Master Trip (3); LD0.TRPPTRC4 Master Trip (4)

BitA RegA IEC 61850 name SA name Description Values
.mcd
.SPCSO9.stVal Ouput state 9 0/1=Off/On
.mcd
.SPCSO10.stVal Ouput state 10 0/1=Off/On
.mcd
.SPCSO11.stVal Ouput state 11 0/1=Off/On
.mcd
.SPCSO12.stVal Ouput state 12 0/1=Off/On
.mcd
.SPCSO13.stVal Ouput state 13 0/1=Off/On
.mcd
.SPCSO14.stVal Ouput state 14 0/1=Off/On
.mcd
.SPCSO15.stVal Ouput state 15 0/1=Off/On
.mcd
.SPCSO16.stVal Ouput state 16 0/1=Off/On
.mcd
2.3.2.23 LD0.TRPPTRC3 Master trip (3)
Table 99: LD0.TRPPTRC3 Master trip (3)
BitA
RegA IEC 61850 name SA name Description Values
LD0.TRPPTRC3
.Op.general Op. input signal 1 = Operate
.mcd
.Tr.general Trip output signal 1 = Trip
.mcd
2.3.2.24 LD0.TRPPTRC4 Master trip (4)
Table 100: LD0.TRPPTRC4 Master trip (4)
BitA
RegA IEC 61850 name SA name Description Values
LD0.TRPPTRC4
.Op.general Op. input signal 1 = Operate
.mcd
.Tr.general Trip output signal 1 = Trip
.mcd
1MRS756878 H Section 2
Modbus data mappings
RET615 53
Point List Manual
