ABB RET615 - Page 68

Table 116: Fault record data
RegA Type Scale IEC 61850 name SA name Description Values
LD0.FLTRFRC1 Fault record data
9409 u32 1 .OpCnt.stVal Fault record number (high) 0..999999
9410 (Low word)
9411 i16 1 .ProFnc.stVal Protection function -32768...327
67
9412 u16 100 .Hz.mag Frequency 30…80.00
[Hz]
9413 u16 100 .StrDur.mag Start duration 0...100.00 [%]
9414 u32 1000 .StrOpTm.mag Operate time [ms] (high) 0...999999.99
9
9415 (Low word)
9416 u32 100 .FltPtR.mag Fault resistance 0.00…
1000000.00
ohms
9417
(Low word)
9418 u32 100 .FltDiskm.mag Fault distance 0.00…
9999.99 pu
9419 (Low word)
9420 u16 1 .ActSetGr.stVal Active setting group 1…6
9421 u16 1 .ShotPntr.stVal AR shot pointer value 0...7
Captured values during fault
9422 u16 1000 .Max50DifAA.mag Max. diff. current phs A 0.000...80.00
0 [pu]
9423 u16 1000 .Max50DifAB.mag Max. diff. current phs B 0.000...80.00
0 [pu]
9424 u16 1000 .Max50DifAC.mag Max. diff. current phs C 0.000...80.00
0 [pu]
9425 u16 1000 .Max50RstAA.mag Max. bias current phs A 0.000…
50.000 [pu]
9426 u16 1000 .Max50RstAB.mag Max. bias current phs B 0.000…
50.000 [pu]
9427 u16 1000 .Max50RstAC.mag Max. bias current phs C 0.000…
50.000 [pu]
9428 u16 1000 .DifAPhsA.mag Diff. current phs A 0.000...80.00
0 [pu]
9429 u16 1000 .DifAPhsB.mag Diff. current phs B 0.000...80.00
0 [pu]
9430 u16 1000 .DifAPhsC.mag Diff. current phs C 0.000...80.00
0 [pu]
9431 u16 1000 .RstAPhsA.mag Bias current phs A 0.000…
50.000 [pu]
9432 u16 1000 .RstAPhsB.mag Bias current phs B 0.000…
50.000 [pu]
9433 u16 1000 .RstAPhsC.mag Bias current phs C 0.000…
50.000 [pu]
Table continues on next page
Section 2 1MRS756878 H
Modbus data mappings
62 RET615
Point List Manual
