ABB TRIO-20.0-TL-OUTD-S-US-480

- 103 -
T013C7
7 - Appendix
Environmental sensors
Tables containing the technical data of the main sensors available from ABB are shown below.
Model Output signal
External
power
supply
TRIO
compatible
PVI-AEC-IRR 0...10Vdc YES YES
PVI-AEC-IRR-T 0...10Vdc YES YES
PVI-AEC-RAD-13TC 0...10Vdc YES YES
PVI-AEC-RAD-13-TC-T 0...10Vdc YES YES
PVI-AEC-CONV-T100 0...10Vdc YES YES
PVI-AEC-T1000-INTEGR 0...10Vdc YES YES
PVI-AEC-WIND-COMPACT 0...10Vdc YES YES
PVI-AEC-PYR-1300 0...20mA YES NO
PVI-AEC-T100-ADH 3-wire connection on terminals: RTD1PT100
RTD2PT100 RTD3PT100
NO YES
PVI-AEC-T1000-BOX 3-wire connection on terminals: RTD1PT1000
RTD2PT1000 RTD3PT1000
NO YES
Model Type Gain Offset U.d.M
PVI-AEC-IRR Irradiance sensor 120 0 W/mq
PVI-AEC-IRR-T Irradiance sensor with
integrated cell temp. sensor
Irradiance: 120
Cell temp.:
10.869
Irradiance: 0
Cell temp.:
-20
Irradiance:
W/m2
Cell temp.:
°C
PVI-AEC-RAD-13TC Irradiance sensor 130 0 Wm2
PVI-AEC-RAD-13-TC-T Irradiance sensor with
integrated cell temp. sensor
Irradiance: 130
Cell temp.:
11.507
Irradiance: 0
Cell temp.:
-26.1
Irradiance:
W/m2
Cell temp.:
°C
PVI-AEC-CONV-T100 PT100/0...10V converter 15 -50 °C a 0...10V
PVI-AEC-T1000-INTEGR Ambient temperature sensor
with integrated converter
10 -50 °C
PVI-AEC-WIND-COMPACT Wind speed sensor 5 0 m/s
PVI-AEC-PYR-1300 Pyranometer (0...1300W/m2) 65 0 W/m2
PVI-AEC-T100-ADH Adhesive PT100 module tem-
perature sensor (back cell)
N/A N/A N/A
PVI-AEC-T1000-BOX PT1000 ambient temperature
sensor
N/A N/A N/A
