ABB TRIO-20.0-TL-OUTD-S-US-480

- 96 -
T013C7
7 - Appendix
Efficiency curves
The equipment was designed in compliance with energy conservation standards to avoid waste and unnecessary
leakage. Graphs of the efciency curves of the inverters are shown below. The efciency curves are affected by
technical parameters that are continually being developed and improved and should be considered approximate.
90
91
92
93
94
95
96
97
98
99
100
10% 20% 30% 50% 75% 100%
% Efficiency
% Rated Output Power
TRIO 20.0kW efficiency curve
450 Vdc
700 Vdc
800 Vdc
90
91
92
93
94
95
96
97
98
99
100
10% 20% 30% 50% 75% 100%
% Efficiency
% Rated Output Power
TRIO 27.6kW efficiency curve
520 Vdc
715 Vdc
800 Vdc
