1- Introduction and safety
NOTE: Refer to Arc Fault Detection Self-Test Errors (-A Models Only) in the Troubleshooting,
section 5, for display error messages and instructions to reset fault conditions or manually
start the self-test procedure.
Available versions
The inverters can be divided into two groups according to their rated output power of 20.0 kW or 27.6 kW. For
inverters of equal output power, the differences between models are the congurations of the wiring box. A
description of the wiring box congurations available can be found below.
20.0 kW MODELS
TRIO-20.0-TL-OUTD-S-US-480
TRIO-20.0-TL-OUTD-S-US-480-A
TRIO-20.0-TL-OUTD-S1-US-480
TRIO-20.0-TL-OUTD-S1-US-480-A
TRIO-20.0-TL-OUTD-S1A-US-480
TRIO-20.0-TL-OUTD-S1A-US-480-A
TRIO-20.0-TL-OUTD-S1B-US-480
TRIO-20.0-TL-OUTD-S1B-US-480-A
Dimensions (HxWxD):
41.7 x 27.6 x 11.5 in
1061 x 702 x 292 mm
Weight:
157 lbs./71kg
27.6 kW MODELS
TRIO-27.6-TL-OUTD-S-US-480
TRIO-27.6-TL-OUTD-S-US-480-A
TRIO-27.6-TL-OUTD-S1-US-480
TRIO-27.6-TL-OUTD-S1-US-480-A
TRIO-27.6-TL-OUTD-S1A-US-480
TRIO-27.6-TL-OUTD-S1A-US-480-A
TRIO-27.6-TL-OUTD-S1B-US-480
TRIO-27.6-TL-OUTD-S1B-US-480-A
Dimensions (HxWxD):
41.7 x 27.6 x 11.5 in
1061 x 702 x 292 mm
Weight:
168 lbs/76kg
Wiring box congurations available
TRIO-20/27.6-TL-OUTD-S-US-480 DC Disconnect Switch
TRIO-20/27.6-TL-OUTD-S-US-480-A
DC Disconnect Switch
Integrated PV AFCI Type 1 device for arc fault detection (AFD)
TRIO-20/27.6-TL-OUTD-S1-US-480
DC Disconnect Switch
8 string DC Input Fuses
Class II DC Surge Protection
TRIO-20/27.6-TL-OUTD-S1-US-480-A
DC Disconnect Switch
8 string DC Input Fuses
Class II DC Surge Protection
Integrated PV AFCI Type 1 device for arc fault detection (AFD)
