- 23 -
T007CH3
Labeled illustration of TRIO
01 mounting bracket
02 wiring box
03 inverter
04 coupling connector cover
05 clamp screw
06 optional handles
07 connector screws
08 wiring box cover
31 bottom locking tab for
securing mounting bracket
to wiring box and inverter,
can also be used as exterior
grounding electrode, if
required
32 hole on wiring box cover and
wiring box chassis used to
insert a padlock, if required
3
Mounting and wiring
31
06
05
03
04
08
04
05
02
07
01
32
