4 - Operations
Partial - Displays partial statistics using a counter that can be reset*.
• Time: Partial operating time since the counter was activated.
• E-par: Partial energy produced since the counter was activated.
• PPeak: Peak power value measured since the partial counter was activated.
• Val.: Partial production value calculated with the currency and conversion coefcient set in
the relevant section of the SETTINGS menu.
• CO2: Amount of CO2 saved daily since the counter was activated.
* To reset all the counters of this submenu, press the ENTER button and hold for 3 seconds until
a beep is heard.
Today - Displays the daily statistics:
• E-day: Daily energy produced.
• PPeak: Daily peak power value.
• Val.: Daily production value calculated with the currency and conversion coefcient set in the
relevant section of the SETTINGS.
• CO2: Amount of CO2 saved today
Last 7 days - Last month - Last 30 days - Last 365 days -
Select any one of the above time periods to view the following information:
• E-##: Energy produced over the period selected.
• Val.: Economic gain over the period selected.
• CO2: Amount of CO2 saved for the period selected.
User period - Displays the statistics for a period selected by the user. Use the display keys to set
the start and end date of the period as follows:
Scroll to User Period and press ENTER to open the Start/End date screen.
• Use ENTER to move from one eld to the next (from left to right).
• Use ESC to go back to the previous eld (from right to left).
• Press ESC repeatedly to go back to the previous menus.
To set the day: Press DOWN to scroll numbers from 31 to 1, UP to scroll from 1 to 31.
To set the month: Press DOWN to scroll months from December to January; UP to reverse.
Once the start and end dates for the user periods have been selected, the following data is
available:
• E-use: Energy produced during the selected period.
• Val.: Value of production for the selected period calculated with the currency and conversion
coefcient set in the relevant section of the SETTINGS menu.
• CO2: Amount of CO2 saved during the selected period.
Settings menu
The Settings menu requires a password which allows access to conguration and modication
of the basic inverter settings.
• Press ESC to open the main menus.
• Scroll DOWN to Settings and press ENTER.
• The password screen is populated in the display.
• The default password is 0000; pressing ENTER four times loads four zeroes into the display
and opens the submenus outlined below.
