7. Select <CW> (clockwise) or <CCW> (counterclockwise) as
needed to center the probe over the reagent cartridge.
NOTE: If unable to align the reagent probes,
contact your local Abbott Representative.
8. Select <OK> to save the position.
9. Select <OK> on the MAINTENANCE UTILITIES screen
then select <OK> on the Home All Robotics dialog
window.
Clockwise
Counterclockwise
