AEROSET
®
System Troubleshooting Guide 239
94816-107—November 2004
R1A Probe Cuvette Alignment
1. Select the Maintenance Utilities icon in the Action Area
of the Main Display. The MAINTENANCE UTILITIES
screen displays.
2. Select the Rgt Area 1 tab. The Rgt Area 1 page displays.
Figure 20: MAINTENANCE UTILITIES Screen, Rgt Area 1
Page
3. Select Rgt Arm A Cuv <Adj>.
Rgt Arm A
