Abov MC96F6432 Series User Manual

MC96F6432
108 June 22, 2018 Ver. 2.9
EIFLAG0 (External Interrupt Flag 0 Register) : C0H
7
6
5
4
3
2
1
0
FLAG7
FLAG6
FLAG5
FLAG4
FLAG3
FLAG2
FLAG1
FLAG0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
EIFLAG0[7:0]
When an External Interrupt 0-7 is occurred, the flag becomes ‘1’.
The flag is cleared only by writing ‘0’ to the bit. So, the flag should
be cleared by software. Writing “1” has no effect.
0
External Interrupt 0 ~ 7 not occurred
1
External Interrupt 0 ~ 7 occurred
Note) Do not use the “direct bit test and branch” instruction for input port, more detail information is at
Appendix B.
Example) Avoid direct input port bit test and branch condition as below
If(FLAG0) → if(EIFLAG0 & 0x01)
EIPOL0H (External Interrupt Polarity 0 High Register): A5H
7
6
5
4
3
2
1
0
POL7
POL6
POL5
POL4
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
EIPOL0H[7:0]
External interrupt (EINT7, EINT6, EINT5, EINT4) polarity selection
POLn[1:0]
Description
0
0
No interrupt at any edge
0
1
Interrupt on rising edge
1
0
Interrupt on falling edge
1
1
Interrupt on both of rising and falling edge
Where n =4, 5, 6 and 7
EIPOL0L (External Interrupt Polarity 0 Low Register): A4H
7
6
5
4
3
2
1
0
POL3
POL2
POL1
POL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
EIPOL0L[7:0]
External interrupt (EINT0, EINT1, EINT2, EINT3) polarity selection
POLn[1:0]
Description
0
0
No interrupt at any edge
0
1
Interrupt on rising edge
1
0
Interrupt on falling edge
1
1
Interrupt on both of rising and falling edge
Where n =0, 1, 2 and 3
