Abov MC96F6432 Series User Manual

MC96F6432
June 22, 2018 Ver. 2.9 37
7.3 A/D Converter Characteristics
Table 7-3 A/D Converter Characteristics
(T
A
= -40°C ~ +85°C, VDD= 1.8V ~ 5.5V, VSS= 0V)
Parameter
Symbol
Conditions
MIN
TYP
MAX
Unit
Resolution
–
–
–-
12
–
bit
Integral Non-Linear
INL
AVREF= 2.7V – 5.5V
fx= 8MHz
–
–
±4
LSB
Differential Non-
Linearity
DNL
–
–
±1
Top Offset Error
TOE
–
–
±3
Zero Offset Error
ZOE
–
–
±3
Conversion Time
t
CONV
12bit resolution, 8MHz
20
–
–
us
Analog Input Voltage
V
AIN
–
VSS
–
AVREF
V
Analog Reference
Voltage
AVREF
*Note 3
1.8
–
VDD
Analog Input Leakage
Current
I
AIN
AVREF= 5.12V
–
–
2
uA
ADC Operating Current
I
ADC
Enable
VDD= 5.12V
–
1
2
mA
Disable
–
–
0.1
uA
NOTES) 1. Zero offset error is the difference between 000000000000 and the converted output for zero input
voltage (VSS).
2. Top offset error is the difference between 111111111111 and the converted output for top input
voltage (AVREF).
3. When AVREF is lower than 2.7V, the ADC resolution is worse.
7.4 Power-On Reset Characteristics
Table 7-4 Power-on Reset Characteristics
(T
A
= -40°C ~ +85°C, VDD= 1.8V ~ 5.5V, VSS= 0V)
Parameter
Symbol
Conditions
MIN
TYP
MAX
Unit
RESET Release Level
V
POR
–
–
1.4
–
V
VDD Voltage Rising Time
t
R
–
0.05
–
30.0
V/ms
POR Current
I
POR
–
–
0.2
–
uA
