MC96F6432

300 June 22, 2018 Ver. 2.9

14.2.2.3 Start and Stop Condition

Figure 14.5 Start and Stop Condition

14.2.2.4 Acknowledge Bit

Figure 14.6 Acknowledge on the Serial Bus

Data output

by transmitter

Data output

By receiver

DSCL from

master

clock pulse for acknowledgement

no acknowledge

acknowledge

START condition

STOP condition

DSDA

DSCL

DSDA

DSCL
