11.8.8 Register Map
Table 11-14 Timer 3, 4 Register Map
Name
Address
Dir
Default
Description
T3CNT
1001H (ESFR)
R
00H
Timer 3 Counter Register
T3DR
1001H (ESFR)
W
FFH
Timer 3 Data Register
T3CAPR
1001H (ESFR)
R
00H
Timer 3 Capture Data Register
T3CR
1000H (ESFR)
R/W
00H
Timer 3 Control Register
T4PPRH
1009H (ESFR)
R/W
00H
Timer 4 PWM Period High Register
T4PPRL
1008H (ESFR)
R/W
FFH
Timer 4 PWM Period Low Register
T4ADRH
100BH (ESFR)
R/W
00H
Timer 4 PWM A Duty High Register
T4ADRL
100AH (ESFR)
R/W
7FH
Timer 4 PWM A Duty Low Register
T4BDRH
100DH (ESFR)
R/W
00H
Timer 4 PWM B Duty High Register
T4BDRL
100CH (ESFR)
R/W
7FH
Timer 4 PWM B Duty Low Register
T4CDRH
100FH (ESFR)
R/W
00H
Timer 4 PWM C Duty High Register
T4CDRL
100EH (ESFR)
R/W
7FH
Timer 4 PWM C Duty Low Register
T4DLYA
1010H (ESFR)
R/W
00H
Timer 4 PWM A Delay Register
T4DLYB
1011H (ESFR)
R/W
00H
Timer 4 PWM B Delay Register
T4DLYC
1012H (ESFR)
R/W
00H
Timer 4 PWM C Delay Register
T4DR
1013H (ESFR)
R/W
FFH
Timer 4 Data Register
T4CAPR
1014H (ESFR)
R
00H
Timer 4 Capture Data Register
T4CNT
1015H (ESFR)
R
00H
Timer 4 Counter Register
T4CR
1002H (ESFR)
R/W
00H
Timer 4 Control Register
T4PCR1
1003H (ESFR)
R/W
00H
Timer 4 PWM Control Register 1
T4PCR2
1004H (ESFR)
R/W
00H
Timer 4 PWM Control Register 2
T4PCR3
1005H (ESFR)
R/W
00H
Timer 4 PWM Control Register 3
T4ISR
1006H (ESFR)
R/W
00H
Timer 4 Interrupt Status Register
T4MSK
1007H (ESFR)
R/W
00H
Timer 4 Interrupt Mask Register
