The process can be depicted as following figure when I2C operates in slave receiver mode.
Figure 11.76 Formats and States in the Slave Receiver Mode (USI0)
SLA+W
ACK
DATA
LOST&
S or Sr
Y
N
0x45
ACK
STOP
Y
N
0x44
P
0x20
IDLE
IDLE
Y
GCALL
0x1D
0x95
0x15
From master to slave /
Master command or Data Write
From slave to master
0xxx
Value of Status Register
ACK
Interrupt, SCL0 line is held low
Interrupt after stop command
P
Arbitration lost as master and
addressed as slave
LOST&
General Call Address
GCALL
