Abov MC96F6432 Series User Manual

MC96F6432
June 22, 2018 Ver. 2.9 147
X 1 2 4 5 6 8 M-1 0 1 3 4
Timer 2 clock
Counter
T2ADRH/L
T2 Interrupt
PWM2O
B Match
Repeat Mode(T2MS = 11b) and "Start High"(T2POL = 0b).
Set T2EN
0
Clear and Start
3 7 2
M
A Match
1. T2BDRH/L(5) < T2ADRH/L
PWM2O
A Match
2. T2BDRH/L >= T2ADRH/L
PWM2O
A Match
3. T2BDRH/L = "0000H"
Low Level
X 1 2 4 5 6 8 M-1 0
Timer 2 clock
Counter
T2ADRH/L
T2 Interrupt
PWM2O
B Match
One-shot Mode(T2MS = 10b) and "Start High"(T2POL = 0b).
Set T2EN
0
Clear and Start
3 7
M
A Match
1. T2BDRH/L(5) < T2ADRH/L
PWM2O
A Match
2. T2BDRH/L >= T2ADRH/L
PWM2O
A Match
3. T2BDRH/L = "0000H"
Low Level
Figure 11.28 16-Bit PPG Mode Timming chart for Timer 2
