MC96F6432
June 22, 2018 Ver. 2.9 185
11.10.5 SPI 2 Timing Diagram
SCK2
(CPOL = 1)
MISO2/MOSI2
(Output)
MOSI2/MISO2
(Input)
D0 D1 D2 D3 D4 D5 D6 D7
D0 D1 D2 D3 D4 D5 D6 D7
SCK2
(CPOL = 0)
SS2
SPIIFR
Figure 11.50 SPI 2 Transmit/Receive Timing Diagram at CPHA = 0
SCK2
(CPOL = 1)
MISO2/MOSI2
(Output)
MOSI2/MISO2
(Input)
D0 D1 D2 D3 D4 D5 D6 D7
D0 D1 D2 D3 D4 D5 D6 D7
SCK2
(CPOL = 0)
SS2
SPIIFR
Figure 11.51 SPI 2 Transmit/Receive Timing Diagram at CPHA = 1
