MC96F6432
158 June 22, 2018 Ver. 2.9
11.8.6 10-Bit Timer 4 PWM Mode
The timer 4 has a high speed PWM (Pulse Width Modulation) function. In PWM mode, the 6-channel pins output
up to 10-bit resolution PWM output. This pin should be configured as a PWM output by set PWM4E to ‘1’. When
the value of 2bit +T4CNT and T4PPRH/L are identical in timer 4, a period match signal is generated and the
interrupt of timer 4 occurs. In 10-bit PWM mode, A, B, C, bottom(underflow) match signal are generated when the
10-bit counter value are identical to the value of T4xDRH/L. The period of the PWM output is determined by the
T4PPRH/L (PWM period register), T4xDRH/L (each channel PWM duty register).
PWM Period = [T4PPRH/T4PPRL ] X Source Clock
PWM Duty(A-ch) = [ T4ADRH/T4ADRL ] X Source Clock
Table 11-12 PWM Frequency vs. Resolution at 8 MHz
The POLxA bit of T4PCR3 register decides the polarity of duty cycle. If the duty value is set same to the period
value, the PWM output is determined by the bit POLxA (1: High, 0: Low). And if the duty value is set to "00H", the
PWM output is determined by the bit POLxA (1: Low, 0: High).
Table 11-13 PWM Channel Polarity
