Abov MC96F6432 Series User Manual

MC96F6432
84 June 22, 2018 Ver. 2.9
9.9 Port Function
9.9.1 Port Function Description
Port function control registers consist of Port function selection register 0 ~ 5. (P0FSRH/L ~ P5FSR).
9.9.2 Register description for P0FSRH/L ~ P5FSR
P0FSRH (Port 0 Function Selection High Register) : D3H
7
6
5
4
3
2
1
0
–
–
P0FSRH5
P0FSRH4
P0FSRH3
P0FSRH2
P0FSRH1
P0FSRH0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P0FSRH[5:4]
P07 Function Select
P0FSRH5
P0FSRH4
Description
0
0
I/O Port (EINT5 function possible when
input)
0
1
SEG22 Function
1
0
AN5 Function
1
1
PWM4CB Function
P0FSRH[3:2]
P06 Function Select
P0FSRH3
P0FSRH2
Description
0
0
I/O Port (EINT4 function possible when
input)
0
1
SEG23 Function
1
0
AN4 Function
1
1
PWM4CA Function
P0FSRH[1:0]
P05 Function Select
P0FSRH1
P0FSRH0
Description
0
0
I/O Port (EINT3 function possible when
input)
0
1
SEG24 Function
1
0
AN3 Function
1
1
PWM4BB Function
