7.5 Low Voltage Reset and Low Voltage Indicator Characteristics
Table 7-5 LVR and LVI Characteristics
(T
A
= -40°C ~ +85°C, VDD= 1.8V ~ 5.5V, VSS= 0V)
Parameter
Symbol
Conditions
MIN
TYP
MAX
Unit
Detection Level
V
LVR
V
LVI
The LVR can select all levels but
LVI can select other levels except
1.60V.
–
1.60
1.75
V
1.85
2.00
2.15
1.95
2.10
2.25
2.05
2.20
2.35
2.17
2.32
2.47
2.29
2.44
2.59
2.39
2.59
2.79
2.55
2.75
2.95
2.73
2.93
3.13
2.94
3.14
3.34
3.18
3.38
3.58
3.37
3.67
3.97
3.70
4.00
4.30
4.10
4.40
4.70
Hysteresis
△V
–
–
50
150
mV
Minimum Pulse Width
t
LW
–
100
–
–
us
LVR and LVI Current
I
BL
Enable (Both)
VDD= 3V
–
10.0
15.0
uA
Enable (One of two)
–
8.0
12.0
Disable (Both)
–
–
0.1
