Table 13-2 Boot Process Description
- (INT-OSC 8MHz/8)x256x28h Delay section (=10ms)
-VDD input voltage must rise over than flash operating
voltage for Config read
-about 1.5V ~ 1.6V
-Config Value is determined by
Writing Option
- Rising section to Reset Release Level
-16ms point after POR or Ext_reset
release
- Reset Release section (BIT overflow)
i) after16ms, after External Reset Release (External reset)
ii) 16ms point after POR (POR only)
- BIT is used for Peripheral stability
