MC96F6432
June 22, 2018 Ver. 2.9 301
Figure 14.7 Clock Synchronization during Wait Procedure
Start wait
start HIGH
Host PC
DSCL OUT
Target
Device
DSCL OUT
DSCL
wait HIGH
Maximum
5 T
SCLK
Internal Operation
Acknowledge bit
transmission
minimum 1 T
SCLK
for next byte
transmission
Acknowledge bit
transmission
Minimum
500ns
