MC96F6432
188 June 22, 2018 Ver. 2.9
SPICR (SPI 2 Control Register) : B5H
7
6
5
4
3
2
1
0
SPIEN
FLSB
MS
CPOL
CPHA
DSCR
SCR1
SCR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
SPIEN
This bit controls the SPI 2 operation
0
Disable SPI 2 operation
1
Enable SPI 2 operation
FLSB
This bit selects the data transmission sequence
0
MSB first
1
LSB first
MS
This bit selects whether Master or Slave mode
0
Slave mode
1
Master mode
CPOL
CPHA
This two bits control the serial clock (SCK2) mode.
Clock polarity(CPOL) bit determine SCK2s value at idle mode.
Clcok phase (CPHA) bit determine if data are sampled on the leading or
trailing edge of SCK2.
CPOL
CPHA
Leading edge
Trailing edge
0
0
Sample (Rising)
Setup (Falling)
0
1
Setup (Rising)
Sample (Falling)
1
0
Sample (Falling)
Setup (Rising)
1
1
Setup (Falling)
Sample (Rising)
DSCR
SCR[2:0]
These three bits select the SCK2 rate of the device configured as a
master. When DSCR bit is written one, SCK2 will be doubled in master
mode.
DSCR
SCR1
SCR0
SCK2 frequency
0
0
0
fx/4
0
0
1
fx/16
0
1
0
fx/64
0
1
1
fx/128
1
0
0
fx/2
1
0
1
fx/8
1
1
0
fx/32
1
1
1
fx/64
