MC96F6432
REVISION HISTORY
VERSION 0.0 (January 14, 2011)
VERSION 1.0 (June 27, 2011)
Change ‘Typ/Max’ to “LVR/LVI level” in LVR/LVI electrical characteristics.
Change ‘600/1200/2000 kΩ (Min/Typ/Max)’ to “RX1” in DC electrical characteristics.
Change ‘3/6/9 kHz (Min/Typ/Max)’ to “f
WDTRC
” in INTERNAL WATCH-DOG RC OSCILLATION characteristics.
Remove WDTRC Current Max value at INTERNAL WATCH-DOG RC OSCILLATION characteristics.
Add ‘1.0 μA (Typ)’ to “I
WDTRC
” in INTERNAL WATCH-DOG RC OSCILLATION characteristics.
Add NOTE at ‘T4CK[3:0] bits description’.
Change ‘cleared by software(S/W)’ in TIMER 3/4 BLOCK DIAGRAM.
Deleted AN15 Function in 12-bit A/D converter.
Added VDD18 Function in 12-bit A/D converter
Change ‘2500/5000/10000 kΩ (Min/Typ/Max)’ to “RX2” in DC electrical characteristics.
Change ‘8.0/12.0 uA (Typ/Max) to “Current consumption(one of two)” in LVR/LVI characteristics.
Change ‘10.0/15.0 uA (Typ/Max) to “Current consumption(both)” in LVR/LVI characteristics.
Change ‘±3 (Max)’ to “ILE” in ADC characteristics.
EXTRF/LVRF initial value changed ‘0’ to ‘unknown’.
Add NOTE 3 at LVRF description.
VERSION 1.1 (July 14, 2011)
Added AN15 Function in 12-bit A/D converter.
Deleted VDD18 Function in 12-bit A/D converter
Change ‘2/5/10 kHz (Min/Typ/Max)’ to “f
WDTRC
” in INTERNAL WATCH-DOG RC OSCILLATION characteristics.
Change temperature condition of HIGH FREQUENCY INTERNAL RC OSCILLATOR characteristics.
VERSION 1.2 (July 20, 2011)
The MC96F6232M device name is changed ‘MC96F6232M’ to ‘MC96F6332M’.
VERSION 1.3 (November 23, 2011)
Moved more descriptions at RXC0/RC1 function descriptions.
Moved more descriptions at T0EN function descriptions.
Add NOTE at ‘LVRVS[3:0] bits description’.
Change ‘50.0/80.0 uA (Typ/Max) to “IDD3” in DC electrical characteristics.
Modified the WDTCR.1 bit name.
Add ‘Instructions on how to use the input port’ descriptions.
VERSION 1.4 (January 16, 2012)
Change ‘±1.0%(T
A
= 0°C ~ +50°C)/±2.0%(T
A
= -20°C ~ +85°C)/±3.0%(T
A
= -40°C ~ +85°C)’ @2.0V – 5.5V to
“IRC’s Tolerance” in Internal RC Oscillator characteristics.
Change ‘±4 (Max)’ to “ILE” in ADC electrical characteristics.
Change ‘50/150mV (Typ/Max)’ to “LVR/LVI Hysteresis” in LVR/LVI electrical characteristics.
Retype some typos on I2C Frequency formula and P5FSR’s SFR Address in Table 9-1.
VERSION 1.5 (April 20, 2012)
Change ‘30V/ms (Max)’ to “VDD Voltage Rising Time” in Power-on Reset Electrical characteristics.
Add a “Table 11.27 LCD Frame Frequency” in LCD driver chapter.
Retype a typo at ‘EO Register description’.
VERSION 1.6 (August 6, 2012)
Add a package type, “MC96F6332L(32 LQFP)”.
Retype some typos on ‘Timer 4 and USI0/1’s contents’.
