MC96F6432
June 22, 2018 Ver. 2.9 77
P1OD (P1 Open-drain Selection Register) : 92H
7
6
5
4
3
2
1
0
P17OD
P16OD
P15OD
P14OD
P13OD
P12OD
P11OD
P10OD
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 08H
P1OD[7:0]
Configure Open-drain of P1 Port
0
Push-pull output
1
Open-drain output
P15DB (P1/P5 Debounce Enable Register) : DFH
7
6
5
4
3
2
1
0
–
–
P54DB
P52DB
P17DB
P16DB
P12DB
P11DB
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P54DB
Configure Debounce of P54 Port
0
Disable
1
Enable
P52DB
Configure Debounce of P52 Port
0
Disable
1
Enable
P17DB
Configure Debounce of P17 Port
0
Disable
1
Enable
P16DB
Configure Debounce of P16 Port
0
Disable
1
Enable
P12DB
Configure Debounce of P12 Port
0
Disable
1
Enable
P11DB
Configure Debounce of P11 Port
0
Disable
1
Enable
NOTES) 1. If the same level is not detected on enabled pin three or four times in a row at the sampling clock, the
signal is eliminated as noise.
2. A pulse level should be input for the duration of 3 clock or more to be actually detected as a valid
edge.
3. The port debounce is automatically disabled at stop mode and recovered after stop mode release.
4. Refer to the port 0 debounce enable register (P0DB) for the debounce clock of port 1 and port 5.
