Abov MC96F6432 Series - Page 92

MC96F6432
92 June 22, 2018 Ver. 2.9
P5FSR (Port 5 Function Selection Register) : FFH
7
6
5
4
3
2
1
0
–
–
P5FSR5
P5FSR4
P5FSR3
P5FSR2
P5FSR1
P5FSR0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P5FSR5
P54 Function Select
0
I/O Port (EINT10 function possible when input)
1
SXOUT Function
P5FSR[4:3]
P53 Function Select
P5FSR4
P5FSR3
Description
0
0
I/O Port
0
1
SXIN Function
1
0
T0O/PWM0O Function
1
1
Not used
P5FSR2
P51 Function Select
0
I/O Port
1
XIN Function
P5FSR[1:0]
P50 Function Select
P5FSR1
P5FSR0
Description
0
0
I/O Port
0
1
XOUT Function
1
0
Not used
1
1
Not used
NOTE) Refer to the configure option for the P55/RESETB.
