2. INSTALLATION
2.1. Unpacking and Initial Inspection
Before you install your amplifier, thoroughly read this manual.
First, carefully inspect the cardboard carton and its contents for physical damage.
ACOM ships amplifiers in highly protected containers, but it cannot assure that
mistreatment by shippers will not occur. If damage is evident, notify your dealer
immediately. Delay may void the carrier's warranty.
CAUTION
The packaged weight is about 16 kg and is recommended to be handled by two persons.
Keep all packing materials for possible future amplifier shipment (see Section 8.4.4 Returning to the Service
Provider).
Figure 2-1 | Packaging carton (outside view)
Figure 2-1 | Packaging carton (outside view)
Unpack the amplifier as described below:
• Open the cardboard carton (see Figure 2-1 | Packaging carton (outside view) and
Figure 2-2 | ACOM 700S packaged in a cardboard box, Pos. 1);
• Take out the top secure element
(see Figure 2-2 | ACOM 700S packaged in a cardboard box, Pos. 2);
• Open the internal cardboard carton
(see Figure 2-2 | ACOM 700S packaged in a cardboard box, Pos. 3);
