8. SPECIFICATIONS
8.1. Parameters
a) Standard Frequency Coverage
1.800 - 2.000 MHz (160 m band)
3.500 - 4.000 MHz (80 m band)
5.250 - 5.450 MHz (60 m band)*
7.000 - 7.300 MHz (40 m band)
10.100 - 10.150 MHz (30 m band)
14.000 - 14.350 MHz (20 m band)
18.068 - 18.168 MHz (17 m band)
21.000 - 21.450 MHz (15 m band)
24.890 - 24.990 MHz (12 m band)
28.000 - 29.700 MHz (10 m band)
50.000 - 54.000 MHz (6 m band)*
* Please, refer the applicable regional band plans and laws for specific allocations and
limitations.
In specific business cases, extensions or changes of the frequency coverage can be
discussed, but this must be agreed upon before ordering. In any case, this is not the
producer's obligation and can not be against local rules and laws.
b) Rated Output Power
• 700 W ±0.5 dB, PEP or continuous carrier;
c) Intermodulation Distortions (IMD3)
• Better than 31 dB below the rated PEP;
d) Harmonic and Parasitic Emissions Output Suppression
• Better than 60 dB (65 dB typically);
e) Input and Output Impedances
• Nominal value: 50 Ohm unbalanced, UHF (SO-239) type connectors;
• Input circuit: Broadband, SWR below 1.2:1 (1.1:1 typically), 1.8-54 MHz continuous
range without retuning or switching;
• RF bypass path: SWR - below 1.1:1, 1.8-54 MHz;
• Acceptable SWR at the output load (the antenna): up to 3:1 with proportional power
reduction and up to 1.5:1 for full output power;
