Acom 700S - Firmware Update Procedure

User's Manual | ACOM 700S | 1.8-54 MHz Linear Amplifier
Page 62 of 92 | S e c t i o n MAINTENANCE
April 2024
Suitable "USB to RS-232" converters are:
• FTDI, PN: UT232R-200 (USB (connector type A) to RS-232 (connector D-sub, 9-pin, male), 2 m
cable length)
This converter can be ordered from:
- DigiKey (www.digikey.com), PN: 768-1084-ND;
- Mouser (www.mouser.com), PN: 895-UT232R-200;
- Farnell (www.farnell.com), PN: 2352013.
• FTDI, PN: UT232R-500 (USB (connector type A) to RS-232 (connector D-sub, 9-pin, male), 5 m
cable length)
This converter can be ordered from:
- DigiKey (www.digikey.com), PN: 768-1085-ND;
- TME (www.tme.eu), PN: UT232R-500;
- Mouser (www.mouser.com), PN: 895-UT232R-500;
- Farnell (www.farnell.com), PN: 2352014.
• Digitus, PN: DA-70166 (USB (connector type C) to RS-232 (connector D-sub, 9-pin, male), 1 m
cable length)
This converter can be ordered from:
- TME (www.tme.eu), PN: DA-70166.
7.5.3. Firmware Update Procedure
The firmware update procedure below is based on a PC with Windows 11 operating
system and the use of a "USB to RS-232" converter. The used PC has both RS-232
interfaces:
- "USB to RS-232" interface converter
- RS-232 serial port/interface (in-build).
The sample images below are based on used Terminal S software with a connected
ACOM 500S amplifier. The firmware update procedure is the same for ACOM 700S and
1200S amplifiers.
