Acteon X-MIND prime - Laser Centring and Digital Sensor Specifications

User Manual – Technical characteristics
USER MANUAL • X-MIND prime • (19) • 01/2020 • NXMPEN010C
26
X-ray tube characteristics
Manufacturer
Canon
CEI
Type
D-058
OPX 105-12
Nominal focal spot
0.5 EN 60336
0.5 EN 60336
Inherent filtration
At least 1.0 mm Al eq.
0.5 mm Al eq.
Anode tilt
12.5°
12°
Anode material
Tungsten
Tungsten
Nominal maximum voltage
70 kVp
110 kVp
Filament max current
3 A
4 A
Filament max voltage
3.6 V
6.7 V
Anode thermal capacity
13 kJ
30 kJ
Anode thermal capacity
during continuous
operation
300 W
300 W
Laser centring devices
2 laser beams are used for patient positioning; beams that align the sagittal and
Frankfurt planes (please refer to relevant paragraphs for a detailed explanation).
Wave length
650 nm
Divergence
< 2.0 mRad
Optical power on the working surface
< 1 mW
Laser class
Class 2 laser product according to IEC
standard 60825-1:2007
Digital sensor
Detector type
FFT-CCD area image sensor
Sensible Area (H x L) PAN Sensor
146 x 6 mm
Pixel dimension
48 µm, 96 µm in 2x2 binning
Number of pixels
3072x128
Spatial resolution
4 lp/mm
Sensor cover attenuation equivalent
< 0.4 mm Al eq.
