User Manual – Technical characteristics
USER MANUAL • X-MIND prime • (19) • 01/2020 • NXMPEN010C
29
Figure 5: X-MIND prime dimensions - Wall mounted with floor support version
1524÷2184 (60.0"÷86.0")
975÷1635 (38.4"÷64.4")
797 (31.4")
1107 (43.6")
953 (37.5")
100 (3.9")400 (15.8")
