User Manual – Technical characteristics
USER MANUAL • X-MIND prime • (19) • 01/2020 • NXMPEN010C
30
Figure 6: X-MIND prime dimensions - Floor mounted version
1565÷2225 (61.6"÷87.6")
991÷1651 (39.0"÷65.0")
962 (37.9")
1272 (50.0")
953 (37.5")
790 (31.1") 996 (39.2")
15 (0.6")
