6146/6156 DC Voltage/Current Generators Operation Manual
3.2 Function Description
3-2
3.2 Function Description
This section describes the panel keys and the parameter functions in alphabetical order.
3.2.1 DATA key (Direct Data Input Mode)
Switches into the direct data input mode that can input numeral data and displays the setting value at half-
brightness.
In this status, green colored functions on the panel are enabled.
Press EXIT to revert to the value when shifted to the direct input mode and then release the direct data
input mode.
3.2.2 DOWN Key (Source Range Down)
Decreases the source range by one step. However, it is impossible to decrease to the range that cannot out-
put the currently set source value.
3.2.3 LIMIT Key (Voltage and Current Limiter Setting)
Switches between the source value setting screen and the limit value setting screen.
3.2.4 MEM Key (Memory Setting)
Displays the memory data setting and recall screen.
Up to 5000 memory data (No. 0000 to No. 4999) in which source functions, output levels and ranges are
separately set can be stored.
NOTE: After setting memory data, be sure to save it. Unsaved memory data is erased at power OFF.
When the 6144-compatible mode is set, 160 memory data (No. 000 to No. 159) are available.
3.2.5 MENU Key (Parameter Setting)
Pressing the MENU key displays the parameter group setting screen.
Select an item from 1.. SOURC to 9.. SYS in the Category level menu with , or .
For more information on set items and the setting method, refer to Section 2.2.3, "Menu Operation."
