6146/6156 DC Voltage/Current Generators Operation Manual
3.2.5 MENU Key (Parameter Setting)
3-7
USER1: Saves the current setting parameters in non-volatile
memory,USER1.
USER2: Saves the current setting parameters in non-volatile
memory,USER2.
USER3: Saves the current setting parameters in non-volatile
memory,USER3.
LOAD Loads the setting parameters saved in the non-volatile memory.
Not displayed on the menu screen while Operate is ON.
USER0: Loads the data in non-volatile memory, USER0 as
the setting parameters.
USER1: Loads the data in non-volatile memory, USER1 as
the setting parameters.
USER2: Loads the data in non-volatile memory, USER2 as
the setting parameters.
USER3: Loads the data in non-volatile memory, USER3 as
the setting parameters.
DFLT: Loads the factory default values as the setting
parameters.
INIT Initializes all the setting parameters set in the 6146/6156.
PARAM DFLT: Initializes the setting parameters.
I/F Selects or sets the interface.
BUS Selects the interface.
GPIB: Selects the GPIB interface.
USB: Selects the USB interface.
BCD: Selects the BCD interface.
NOTE: Displayed only when the BCD interface option is
installed.
GP.Adr Sets the GPIB address from 0 to 30.
NOTE: NOT displayed when the USB interface is selected.
USBid Sets the USB ID from 1 to 127.
NOTE: NOT displayed when the GPIB interface is selected.
L.ONLY Switches between Addressable and Listen Only.
NOTE: NOT displayed when the USB interface is selected.
ON: Listen Only
OFF: Addressable
6144 Sets the 6144-compatible mode.
ON: Sets the 6144-compatible mode to ON.
To Next Page
