6146/6156 DC Voltage/Current Generators Operation Manual
5.4 USB
5-12
5.4 USB
5.4.1 Overview
The 6146/6156 is USB (Universal Serial Bus) equipped conforming to USB 2.0 standard.
USB allows function settings and reading of measurement data with respect to multiple instruments con-
nected to the bus using a PC, making it simple to configure an automated measurement system.
NOTE: All operations using a PC or hub cannot be guaranteed.
5.4.2 USB Specifications
• Standard: Complies with USB2.0 Full-Speed
• Connectors: USB B type (female)
• Identifier ID: USB ID, settable from 1 to 127
• Remote/Local: Available
• Input commands: Function setting and query with ASCII character string commands
• Output format: Measurement data and query response with ASCII character string com-
mands
• Driver: ADC Instruments USB Driver 2.3.0 or later
5.4.3 Setting Up USB
5.4.3.1 Connecting with PC
Connect the USB connector (B type) on the rear of the 6146/6156 to the PC USB connector with a cable.
Fully insert all connectors.
Use a USB hub to connect multiple instruments to a single PC.
To Next Page
