6146/6156 DC Voltage/Current Generators Operation Manual
5.7 Source Value Output Format (Talker Format)
5-25
5.7 Source Value Output Format (Talker Format)
The source values are read out in the following formats.
1. Read out by a query command
2. Read out Not by a query command
The current source value can be always read by specifying the 6146/6156 as Talker and receiving data
without sending a query command.
Query command Response
Range 6146 6156
SOV? 30 mV SOV±dd.dddE-3 SOV±dd.ddddE-3
300 mV SOV±ddd.ddE-3 SOV±ddd.dddE-3
3 V SOV±d.ddddE+0 SOV±d.dddddE+0
30 V SOV±dd.dddE+0 SOV±dd.ddddE+0
SOI? 3 mA SOI±d.ddddE-3 SOI±d.dddddE-3
30 mA SOI±dd.dddE-3 SOI±dd.ddddE-3
200 mA SOI±ddd.ddE-3 SOI±ddd.dddE-3
TMP? *1 - TMP±dddd.dE+0
D? 30 mV DV±d.ddddE-2 DV±d.dddddE-2
300 mV DV±d.ddddE-1 DV±d.dddddE-1
3 V DV±d.ddddE+0 DV±d.dddddE+0
30 V DV±d.ddddE+1 DV±d.dddddE+1
3 mA DI±d.ddddE-3 DI±d.dddddE-3
30 mA DI±d.ddddE-2 DI±d.dddddE-2
200 mA DI±d.ddddE-1 DI±d.dddddE-1
6144-compatible mode
D? 30 mV DV±d.ddddE-2
300 mV DV±d.ddddE-1
3 V DV±d.ddddE+0
30 V DV±d.ddddE+1
3 mA DI±d.ddddE-3
30 mA DI±d.ddddE-2
*2 200 mA DI±
d.ddddE-1
*1 : The thermal electromotive force output function is available on the 6156
only.
*2 : The lowest digit of the 6156 is not output.
