6146/6156 DC Voltage/Current Generators Operation Manual
5.7 Source Value Output Format (Talker Format)
5-26
• Talker format in the normal mode
• Talker format in the 6144-compatible mode
3. Block delimiter
The block delimiter is output to show the end of data.
These are commands that can specify a block delimiter.
Function
6146 6156
Range
Voltage 30 mV SOV±dd.dddE-3 SOV±dd.ddddE-3
300 mV SOV±ddd.ddE-3 SOV±ddd.dddE-3
3 V SOV±d.ddddE+0 SOV±d.dddddE+0
30 V SOV±dd.dddE+0 SOV±dd.ddddE+0
Current 3 mA SOI±d.ddddE-3 SOI±d.dddddE-3
30 mA SOI±dd.dddE-3 SOI±dd.ddddE-3
200 mA SOI±ddd.ddE-3 SOI±ddd.dddE-3
Thermal electromotive force *1 - TMP±dddd.dE+0
Function
6146 6156 *2
Range
Voltage 30 mV DV±d.ddddE-2
300 mV DV±d.ddddE-1
3 V DV±d.ddddE+0
30 V DV±d.ddddE+1
Current 3 mA DI±d.ddddE-3
30 mA DI±d.ddddE-2
200 mA DI±d.ddddE-1
Thermal electromotive force *1 - TMP±dddd.dE+0
*1 : The thermal electromotive force output function is available on the 6156 only.
*2 : The lowest digit of the 6156 is not output.
Block delimiter Setting command Default
CR LF+EOI DL0
LF DL1
EOI DL2
LF+EOI DL3
(EOI is a GPIB function. It is not output by USB.)
