6146/6156 DC Voltage/Current Generators Operation Manual
7. CALIBRATION
7-1
7. CALIBRATION
This chapter describes how to calibrate the 6146/6156 to perform within the specified accuracy ranges.
In order to use the 6146/6156 in the specified accuracies, periodic calibration at least once a year is recom-
mended. (To secure the 90-day accuracy, execute calibration once every 90 days.)
Contact an ADC CORPORATION sales representative for the calibration service.
7.1 Preparation for Calibration
7.1.1 Measuring Instrument and Cables Necessary for Calibration
The following table shows the accuracy of each range and cables necessary for calibration.
Table 7-1 Accuracies and Cables Necessary for Calibration
Function Range
± ZERO ± FS Standard resistance
Cable
Calibration
point
Required
accuracy
Calibration
point
Required accuracy
Resist-
ance
Required
accuracy
6146 6156 6146 6156 6146 6156
Voltage
source
30 mV
± 0 V
2 μV1.5 μV ± 30 mV 60 ppm 60 ppm
--
A01044
(Supplied
accessory)
*1
A01035
300 mV 2 μV1.5 μV ± 300 mV 40 ppm 15 ppm
3 V 20 μV5 μV ± 3 V 40 ppm 10 ppm
30 V 200 μV 50 μV ± 30 V 40 ppm 20 ppm
Current
source
(using a
shunt
resistance)
3 mA
*2
± 0 V
(± 0 mA)
2 nA 1.5 nA ± 300 mV
(± 3 mA)
40 ppm 15 ppm 1000 Ω
20 ppm 20 ppm
A01044
(Supplied
accessory)
*1
A01035
30 mA
*2
20 nA 15 nA ± 300 mV
(± 30 mA)
40 ppm 15 ppm 100 Ω
200 mA
*2
200 nA 150 nA ± 200 mV
(± 200 mA)
40 ppm 15 ppm 1 Ω
50 ppm 30 ppm
Current
source
(using DCI
of DMM)
3 mA
± 0 V
(± 0 mA)
2 nA 1.5 nA ± 3 mA 60 ppm 35 ppm
--
A01044
(Supplied
accessory)
*1
30 mA 20 nA 15 nA ± 30 mA 60 ppm 35 ppm
200 mA 200 nA 150 nA ± 200 mA 90 ppm 45 ppm
Voltage
limiter
30 V ± 1 V 200 μV ± 30 V 100 ppm - - Same as voltage
source
Current
limiter
200 mA ±5 mA 200 nA ± 200 mA 100 ppm - - Same as voltage
source
DAC
calibration
---1 μV
*3
- - 0.5 ppm
*3
- - Same as voltage
source
*1 : When much externally induced noise exists, use shielded cables, such as A01001, etc.
*2 : Each rang of the current source and the current limiter is calibrated using voltage conversion with a stan-
dard resistance.
*3 : Stability for 24 hours
