6146/6156 DC Voltage/Current Generators Operation Manual
8.1 Voltage/Current Source
8-5
Maximum load inductance: Maximum value that does not oscillate in current source or current limiter
Current source/current limiter: 1 mH
CMRR: Voltage output 100 dB or higher
Current output 72 dB or higher
At unbalanced impedance 1 kΩ and in DC and AC 50/60 Hz ± 0.1%
Voltage/current limiter:
Setting range Resolution Setting accuracy
Voltage limiter 1 V to 32 V 100 mV ±5 % of setting ±100 mV
Current limiter 5 mA to 220 mA 1 mA ±10 % of setting ±1 mA+60 μA/1 V
The current limiter is available in the 3 V and 30 V ranges.
