6146/6156 DC Voltage/Current Generators Operation Manual
8.3 General Specifications
8-7
External control signal: TRIGGER IN
READY OUT/SYNC OUT
STANDBY IN, OPERATE/STANBY IN, INTERLOCK, OPERATE OUT,
OPERATE/SUSPEND IN
Connector; BNC
Operate hold function: Starts up with output ON at recover from a power failure.
8.3 General Specifications
Operating environment conditions:
Ambient temperature 0°C to +50°C, relative humidity 85% or below, with no
condensation
Storage environment conditions:
Ambient temperature -25°C to +70°C, relative humidity 85% or below, with
no condensation
Warming up time: 30 minutes or longer
Display: 15-digit decimal (6146)/6-digit decimal (6156)
7-segment vacuum fluorescent display
Power supply: AC power 100 V, 120 V, 220 V, and 240 V (User selectable)
Line frequency: 50Hz/60Hz
Power consumption: 56 VA or less
Dimensions: Approx. 212 (width) × 88 (height) × 340 (depth) mm
Mass: 4 kg or less
Safety: Compliant with IEC61010-1 Ed.3
EMI: Compliant with EN61326 classA
Option No. Standard OPT.32 OPT.42 OPT.44
Power voltage 100 V 120 V 220 V 240 V
Specify the option number when ordering.
When changing the power voltage, use only a power cable and rated
fuse approved for the respective country.
