6146/6
156 DC V
oltage/Current G
enerators
Operation Manu
al
2.2.6
Count Fix Functi
on
2-33
Changing the range with the count fix set to ON (CO.FIX.ON)
Example usin
g the 6156
The cursor
position does no
t change at the rang
e change.
UP
(300 mV rang
e)
Source val
ue: 101 mV
(30 mV
range)
Source valu
e: 10.1 mV
Cursor (blin
king)
Cursor (blink
ing)
UP
UP
(30 V r
ange)
Source valu
e: 10.1 V
(3 V r
ang
e)
Source value: 1.01 V
Cursor (blink
ing)
Cursor (blink
ing)
66
