6146/6156 DC Voltage/Current Generators Operation Manual
2.3.1 Memory Recall Mode
2-37
4. Set the source value to 5 V with , or .
Direct data input using DATA is also available.
5. Move the cursor onto the memory number with , or SEL (STEP TIME).
6. Set the memory number to "1" with or .
Direct data input using DATA is also available.
7. Press V/I once to set the current function.
8. Press UP once to select 30 mA range.
9. Press once to set the polarity to negative.
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
-
