6146/6156 DC Voltage/Current Generators Operation Manual
2.3.1 Memory Recall Mode
2-38
10. Move the cursor onto the source value with , or SEL (STEP TIME).
11. Set the source value to -30 mA with , or .
Direct data input using DATA is also available.
12. Move the cursor onto the memory number with , or SEL (STEP TIME).
13. Set the memory number to "2" with , or DATA.
14. Press V/I twice to set the thermal electromotive force output function.
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
"n" indicates JIS C1602 1995 (new JIS). Type of thermocouple
