6146/6156 DC Voltage/Current Generators Operation Manual
2.3.1 Memory Recall Mode
2-39
15. Press UP three times to select thermocouple type K.
16. Move the cursor onto the memory number with , or SEL (STEP
TIME).
17. Set the source value to 300°C with , or .
Direct data input using DATA is also available.
18. Move the cursor to the position indicated in the figure below with or .
19. Change from "n" to "o" with , or .
20. Press MEM or EXIT to return to the HOME screen.
2.3.1.1.2 Saving Memory Data to Nonvolatile Memory
As the input memory data is saved in the volatile memory (RAM), it needs to be saved to the nonvolatile
memory (Flash ROM) so as not to be erased at power OFF.
The saved data is automatically loaded onto the volatile memory (RAM) at power ON.
The memory data is saved using MENU, MEM and M.SAVE.
Cursor (blinking)
Half-brightness
Type of thermocouple
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
"o" indicates JIS C1602 1981 (former JIS).
To Next Page
