ADRF SDR - Repeater Quick View

Advanced RF Technologies, Inc.
14
1.3 Repeater Quick View
Figure 2 Repeater Quick View
LED indicator
19” rackmount
holes
Host / Remote Switch
& RJ-45 port
NMS Output
Power Port
RJ-45 Module
Communication
Port
Battery Backup
Port
Module power
switch & AC IN
Master AC IN
DC Out for external
modem box
NMS Communication
Hub
NMS Input Power Port
NMS Power Switch
AC Select Switch
SDR-33-AF
