SMD17E2 SPECIFICATIONS
SMD17E2 User Manual
ADVANCED MICRO CONTROLS INC.
24
Compatible Connectors and Cordsets (continued)
Ethernet Cordset
Table R1.7 Ethernet Cordset
Power Cordsets
Table R1.8 Power Cordsets
AMCI Part # Description
CNER-5M
4-position, 24 AWG, shielded. EIA/TIA 568B color coded.
Connectors: Straight M12, D-coded, Male to RJ45.
Shield attached to both connectors.
Cable length: 5 m
AMCI Part # Description
CNPL-2M
5-position, 18 AWG.
Connector: Straight M12, A-coded, Female to 2 inch flying leads, 0.28” stripped.
Cable length: 2 m
CNPL-5M
5-position, 18 AWG.
Connector: Straight M12, A-coded, Female to 2 inch flying leads, 0.28” stripped.
Cable length: 5 m
