3 EKI-1526(TI) | 1528(TI) User Manual
1.3 Device Specifications
Specifications Description
Interface I/O Ports
2 x RJ45
8 or 16 x RS-232/422/485
See the Ethernet Communications and Serial Com-
munications
Power Connector
2-pin removable screw terminal (power & relay)
Power socket
Physical Enclosure SECC chassis
Installation Rack
Dimensions
(W x H x D)
438 x 43.6 x 259.2 mm (17.24" x 1.71" x 10.2")
LED Display System LED Power, Status
Port LED
LAN: Speed, Link/Active
Serial: Tx, Rx
Environment Operating
Temperature
-40°C ~ 75°C (-40°F ~ 167°F)
Storage
Temperature
-20°C ~ 80°C (-4°F ~ 176°F)
Ambient Relative
Humidity
10 ~ 95% (non-condensing)
Ethernet
Communications
Compatibility IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Speed 10/100/1000 Mbps, auto MDI/MDIX
Port Connector 8-pin RJ45
Ports 2 x RJ45
Protection Built-in 1.5 KV magnetic isolation
Serial
Communications
Port Type RS-232/422/485, software selectable
Ports
EKI-1528/EKI-1528I/EKI-1528TI: 8
EKI-1526/EKI-1526I/EKI-1526TI: 16
Port Connector DB9 male
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Parity None, Odd, Even, Space, Mark
Flow Control XON/XOFF, RTS/CTS, DTR/DSR
Baud Rate 50 bps ~ 976.5 kbps, any baud rate setting
16 ports up to 230.4 kbps simultaneously
Protection Built-in 15 KV ESD for all signals
Power Power
Consumption
5.6W
Power Input
EKI-1528(I)/EKI-1526(I): 100 ~ 240 V
AC
, 50 ~
60 Hz
EKI-1528T(I)/EKI-1526T(I): 12 ~ 48 V
DC
, Termi-
nal Block
