11 EKI-1526(TI) | 1528(TI) User Manual
The following view shows the EKI-1526T/EKI-1526TI.
Figure 2.11 EKI-1526T/EKI-1526TI Dimensions
LAN1 LAN2
5
1
6
2
7
3
8
4
13
91110
14 15
12
16
8.65 [0.34]
12
[0.47]
9.60
[0.38]
43.60
[1.72]
259.20 [10.21]
438 [17.24]
