EKI-1526(TI) | 1528(TI) User Manual 54
6.4 Ethernet Configuration
Choose either Eth 1 or Eth 2 in the Ethernet Configuration page.Enter the corre-
sponding values for your network environment. Remember press Save after fill in all
values.
To access this page, click Ethernet Configuration.
Figure 6.3 Ethernet Configuration
The following table describes the items in the previous figure.
Time Server Enter the address of the SNTP server. This is a text string of up to 64
characters containing the encoded unicast IP address or hostname of
a SNTP server. Unicast SNTP requests will be sent to this address. If
this address is a DNS hostname, then that hostname should be
resolved into an IP address each time a SNTP request is sent to it.
Save Click Save to save the values and update the screen.
Item Description
Item Description
IPv4 Configuration
Mode Click the drop-down menu to select the IP Address Setting mode:
Static IP, DHCP, or BOOTP.
MAC Address Enter the MAC address to which packets are statically forwarded.
IP Address Enter a value to specify the IP address of the interface. The default is
10.0.0.1 (Eth1) & (0.0.0.2 (Eth2).
Subnet Mask Enter a value to specify the IP subnet mask for the interface. The
default is 255.0.0.0.
Default Gateway Enter a value to specify the default gateway for the interface.
